Counter UAV Drone Professional GNSS Spoofer | Anti-Drone GNSS Spoofing & Navigation Satellite Deception Equipment for Defense Systems
| 원래 장소 | 선전 |
|---|---|
| 브랜드 이름 | Ladasky |
| 모델 번호 | LDSK-AY06/LDSK-AY13/LDSK-AY22 |
| 최소 주문 수량 | 1 |
| 가격 | $7858-$25000 |
| 배달 시간 | 5~8일 |
| 지불 조건 | L/C,D/A,T/T,D/P,웨스턴 유니온,MoneyGram |
| 공급 능력 | 5000pcs/월 |
무료 샘플과 쿠폰을 받으려면 연락하세요.
왓츠앱:0086 18588475571
웨이 채팅: 0086 18588475571
스카이프: sales10@aixton.com
궁금한 점이 있으시면 24시간 온라인 도움을 제공합니다.
x제품 상세 정보
| 범위 | 5km-20km 맞춤형 가능 | 스푸핑 방법 | 방향유도, 억제, 강제착륙, 급속충돌 등이 그것이다. |
|---|---|---|---|
| 항법 신호 | GPS, BDS, GLONASS, Galileo, QZSS 및 IRNSS(사용자 정의 가능) | 치수 | 430*370*175mm (안테나 제외) |
| 외부 공급 전압 | AC 110-300V | ||
| 강조하다 | Portable drone detector with GNSS spoofer,Anti-drone GNSS spoofing equipment,Navigation satellite deception defense system |
||
제품 설명
Counter UAV Drone Professional GNSS Spoofer
Anti-Drone GNSS Spoofing & Navigation Satellite Deception Equipment for Defense Systems
Navigation Satellite Deception Equipment
This professional counter-drone equipment is specifically designed for security applications in oil and petrochemical facilities, power plants, public security operations, and military installations. Featuring a compact, lightweight design with reliable performance and user-friendly operation, it enables rapid deployment and integration. Utilizing advanced navigation satellite signal simulation technology, the system broadcasts simulated satellite signals identical to operational navigation satellites. When drones receive these signals, they use them for positioning, allowing the system to implement multiple deception strategies including heading guidance, deterrence, forced landing, and rapid crash protocols.
Product Features
- Supports signal reception and simulated transmission from all four major global navigation satellite systems, plus commonly used frequencies in Japan and India
- Performs navigation deception on UAVs relying on satellite navigation, achieving objectives including forced landing, heading guidance, takeoff prohibition, and signal interference
- Compatible with external direction finding modules for target azimuth identification and horizontal movement control (forward, backward, left, right)
- Supports external command control for arbitrary navigation signal combination transmission
- Configurable position coordinates (longitude, latitude, altitude) via external commands or built-in fixed coordinates
- Adjustable simulation parameters including signal delay, motion speed, and acceleration via external commands
- Supports preset trajectories such as linear motion and circular motion via external commands
- Accepts externally added motion trajectories; calculates and outputs corresponding navigation satellite signals
- Operates in both real-time ephemeris mode and permanent ephemeris mode
- Provides satellite navigation signal suppression and interference output capabilities
- Includes network secondary development control interface for system integration
Technical Specifications
Performance Parameters
| Item | Specification |
|---|---|
| Deception Distance | Customizable according to customer requirements |
| Supported GNSS Systems | GPS, BDS, GLONASS, Galileo |
| Receiving Frequencies | BDS-B1, GPS-L1 / L2 / L5, GLONASS-L1, Galileo-E1 |
| Attenuation Adjustment Range | 80 dB |
| Attenuation Resolution | 1 dB |
| Power-on Startup Time | 60 s |
| GNSS Signal Synchronization Time | < 180 s |
GNSS Signal Simulation Capability
| No. | Satellite System | Frequency Band | Channels |
|---|---|---|---|
| 1 | BDS | B1I | 16 |
| 2 | GPS | L1 C/A | 16 |
| 3 | GPS | L2 | 16 |
| 4 | GPS | L5 | 16 |
| 5 | GLONASS | L1 | 16 |
| 6 | Galileo | E1 | 16 |
Distance vs Output Power Reference
| Deception Distance | Output Power |
|---|---|
| 5 km | 5 W |
| 10 km | 20 W |
| 20 km | 50 W |
